首页 >> 直线导轨 >> HIWIN直线导轨HGW-CA/HA系列尺寸表 |
|
型号 |
组件尺寸 |
滑块尺寸 |
导轨尺寸 |
|
H |
H1 |
N |
W |
B |
B1 |
C |
L1 |
L |
G |
M |
T |
T1 |
H2 |
H3 |
WR |
HR |
D |
h |
d |
P |
E |
HGW15CA |
24 |
4.3 |
16 |
47 |
38 |
4.5 |
30 |
39.4 |
61.4 |
5.3 |
M5 |
6 |
8.9 |
4.5 |
5.5 |
15 |
15 |
7.5 |
5.3 |
4.5 |
60 |
20 |
HGW20CA |
30 |
4.6 |
21.5 |
63 |
53 |
5 |
40 |
50.5 |
75.6 |
12 |
M6 |
8 |
10 |
6 |
7 |
20 |
17.5 |
9.5 |
8.5 |
6 |
60 |
20 |
HGW20HA |
65.2 |
90.3 |
HGW25CA |
36 |
5.5 |
23.5 |
70 |
57 |
6.5 |
45 |
58 |
83 |
12 |
M8 |
8 |
14 |
6 |
9 |
23 |
22 |
11 |
9 |
7 |
60 |
20 |
HGW25HA |
78.6 |
103.6 |
HGW30CA |
42 |
6 |
31 |
90 |
72 |
9 |
52 |
70 |
97.4 |
12 |
M10 |
8.5 |
16 |
6.5 |
11 |
28 |
26 |
14 |
12 |
9 |
80 |
20 |
HGW30HA |
93 |
120.4 |
HGW35CA |
48 |
7.5 |
33 |
100 |
82 |
9 |
62 |
80 |
112.4 |
12 |
M10 |
10.1 |
18 |
9 |
13 |
34 |
29 |
14 |
12 |
9 |
80 |
20 |
HGW35HA |
105.8 |
138.2 |
HGW45CA |
60 |
9.5 |
37.5 |
120 |
100 |
10 |
80 |
97 |
138 |
12.9 |
M12 |
15.1 |
22 |
8.5 |
21 |
45 |
38 |
20 |
17 |
14 |
105 |
22.5 |
HGW45HA |
128.8 |
169.8 |
HGW55CA |
70 |
13 |
43.5 |
140 |
116 |
12 |
95 |
117.7 |
165.7 |
12.9 |
M14 |
17.5 |
26.5 |
12 |
19 |
53 |
44 |
23 |
20 |
16 |
120 |
30 |
HGW55HA |
155.8 |
203.8 |
HGW65CA |
90 |
15 |
53.5 |
170 |
142 |
14 |
110 |
144.2 |
198.2 |
12.9 |
M16 |
25 |
37.5 |
15 |
15 |
63 |
53 |
26 |
22 |
18 |
150 |
35 |
HGW65HA |
203.6 |
257.6 |
导轨固定螺栓尺寸 |
基本动额定载荷 |
基本静额定载荷 |
静态额定力矩 |
重量 |
型号 |
MR |
MP |
MY |
滑块 |
滑轨 |
(mm) |
C(kN) |
C0(kN) |
kN-m |
kN-m |
kN-m |
kg |
kg/m |
M4×16 |
11.38 |
25.31 |
0.17 |
0.15 |
0.15 |
0.17 |
1.45 |
HGW15CA |
M5×16 |
17.75 |
37.84 |
0.38 |
0.27 |
0.27 |
0.40 |
2.21 |
HGW20CA |
21.18 |
48.84 |
0.48 |
0.47 |
0.47 |
0.52 |
HGW20HA |
M6×20 |
26.48 |
56.19 |
0.64 |
0.51 |
0.51 |
0.59 |
3.21 |
HGW25CA |
32.75 |
76.00 |
0.87 |
0.88 |
0.88 |
0.80 |
HGW25HA |
M8×25 |
38.74 |
83.06 |
1.06 |
0.85 |
0.85 |
1.09 |
4.47 |
HGW30CA |
47.27 |
110.13 |
1.40 |
1.47 |
1.47 |
1.44 |
HGW30HA |
M8×25 |
49.52 |
102.87 |
1.73 |
1.20 |
1.20 |
1.56 |
6.3 |
HGW35CA |
60.21 |
136.31 |
2.29 |
2.08 |
2.08 |
2.06 |
HGW35HA |
M12×35 |
77.57 |
155.93 |
3.01 |
2.35 |
2.35 |
2.79 |
10.41 |
HGW45CA |
94.54 |
207.12 |
4.00 |
4.07 |
4.07 |
3.69 |
HGW45HA |
M14×45 |
114.44 |
227.81 |
5.66 |
4.06 |
4.06 |
4.52 |
15.08 |
HGW55CA |
139.35 |
301.26 |
7.49 |
7.01 |
7.01 |
5.96 |
HGW55HA |
M16×50 |
163.63 |
324.71 |
10.02 |
6.44 |
6.44 |
9.17 |
21.18 |
HGW65CA |
208.36 |
457.15 |
14.15 |
11.12 |
11.12 |
12.89 |
HGW65HA |
